PRODUCT > Printing UV Curing System > Label UV Curing System
> Rotary |
|
|
 |
|
|
 |
|
- Rotary Curing Machine |
 |
|
| Model |
UT-3500M |
|
| Type |
PLC program |
| Power |
3.5KW |
| Use |
Rotary Printing Machinery |
| Power
Supply |
220V/380V, 50Hz/60Hz |
| Lamp
Name |
Mtal Halide
Lamp |
| Lamp
Size |
250 * 350 |
| Reflector |
Cold Mirror
/ Hot Mirror |
| Cooling |
Air Cooling |
| Monitor |
Touch screen |
|
|
|
● This machine is designed for Letterpress Printing Machine.
● The rotary printing machine has been developed in a compact design.
● Installed with Select Mode, it can automatically control the output of the UV Lamp to adjust to the velocity
of the printing machine.
● PLC Program Operation and Touch Screen, which can change printing programs easily, make its operation
much more convenient.
● Multi-guide inspection display interfaces, which can show the state of equipment and error messages on
its monitor, facilitates its maintenance and repair.
● It has an effective cooling system which can ensure low temperature cure of the printed material by using
Cold Mirror/ Hot Mirror.
● The metal halide lamp is used as a light source for a photochemical reaction such as a curing light source
for printing ink, instead of a mercury lamp.
● UV curing technology provides High-Speed Printing.
● Possible to change the size of lamp, depending on the printing paper width
● Clients: SANKI, TaeKyoung Hi Tech Co., KOPEC, BangSung Machinery Co., Doil Industry Co.,
SANJO, HIKARI, IWASAKI, and so on. |
|
|
|
|
|
